DAFTAR KUANTITAS DAN HARGA

Kompetensi Keahlian Teknik  Konstruksi Gedung, Sanitasi dan perawatan
NO    Kode Juknis    URAIAN    SATUAN /UKURAN    VOLUME    HARGA SATUAN (Rp)    JUMLAH HARGA (Rp)

I
1    2.1    Manual Arc Welding    Unit    3     18.978.000      56.934.000
2    2.2    Angle Grinder    Unit    8     1.845.000      14.760.000
3    2.3    Cut Off Machine    Unit    4     3.750.000      15.000.000
4    2.12    Portable Planner    Unit    4     3.200.000      12.800.000
5    2.11    Portable Circular Saw    Unit    4     6.500.000      26.000.000
6    2.13    Surface Planner    Unit    1     46.506.000      46.506.000
                         172.000.000
SPESIFIKASI TEKNIS

Spesifikasi
3
    S201i MMA PACKAGE
The Handy Series at a glance
● Extremely robust with minimal weight
● Guaranteed protection against falls of up to 80 cm in height
● Outstabdubg welding charateristics thanks to state-of-the-art inverter technology
● Especially suitable for basic ,rutile and special electrodes
● With Hotstart, Anti-Stick and Arc-Force regulation technology
● InsideCoating: optimum dust protection for a long service life
● Full power even in the case of voltage fluctuations and when using long cables
● Generator-compatible
● Highly efficient and low energy consumpation due to the most modren power electronics and the fan on demand function
● "3 steps to weld" - operating concept
● Manufactured and tested according to DIN EN 60974-1, Whit CE mark,S-symbol and IP 23
3 Steps to achieve weld prfection
● Swith on
● Select process / electrode type
● Adjust welding current
Perfect electrode welding
 Th e microprocessor regulation ensures particularly good weld characteristics of the Handy series.  Simply switch on  and
start welding. You will instantly experience impressive work results. We create the technical requirements in the backgroud
for optimum arc regulation with a completely digital signal controller:
● The automatic hotstart provides absolutely perfect ignition characteristics
● The Anti-Stick System prevents the electrode from sticking.
● The arc- Force regulation supports the welding process with an increased arc stability  an doptimised metal transfer.
The base: adaptive regulation technology with the know ledge of the best welders in the word. Because the finer and more
controlledthe droplet transfer, the better your welding result
Specifications:
Welding  range
● Electrode  :  5 - 150 A
● TIG with ContacTIG  :  5 - 160 A
Weldable electrodes
● Electrode Ø in mm  :  1.5 - 4.0
● CEL Ø in mm  : ─
● TIG Ø  IN MM  : 1.0 - 2.4
Standart duty cycle for MMA - electrode measured according to Germa quality standard DIN EN 60974-1
● Current  at 100 % duty cycle (40 ˚C)   :   115 A
● Current  at 60 % duty cycle (40 ˚C)   :   135 A
● Duty cycle I max.(40 ˚C)  31/08/2017  40 %
Machine
● Mains voltage  : 1   ̴ 230 V
● Permitted mains tolerance  :  +15 % /  -25 %
● Mains fuse, delayed action   :  16 A
● Dimensions in mm (L x W x H)   :  337 x 130 x211
● Weight  : 5.3 kg
Equipment versions
Electrode assembly pack (Contents of the electrode assembly pack: 3 m  electrode and ground cable,chipping hammer,
wire brush,welding shield EN 166,welding glasses ,in a robust protective tool case.)
Operating concepts  :  Basic Plus
Accessories:
 ● Welding cable 3Mtr
 ● Electrode holder
 ● Ground cable 2Mtr
 ● Ground damp
 ● Regulator

Specifications    GWS 850 CE
Mains voltage [V]  :  230
Mains frequency [Hz]  :  50
Nominal power [W]  :  850
Diameter of the grinding disk  [mm]   :  125
Diameter of the hole of the grinding disk  [mm]  :  22
Spindle end  :  M14
Specifications :    GCO 200 PRO
Rated voltage [V]  :  230
Rted frequency [Hz]   :   50
Rated power [W]  :  2300
Rated revs [min ‾ ¹]  :  3800
Maximum depth of cutting [mm]  :  100
Depth of cutting at 90˚ (square profile) [mm]  :119 x 119
Depth of cutting at 90˚ (rectangle profile) [mm]  :  115 x 130
Depth of cutting at 90˚ (angle bar) [mm]  :  137 x  137
Depth of cutting at 90˚ (round profile) [mm]  :  100
Depth of cutting at 90˚ (square profile) [mm]  :  94 x94
Depth of cutting at 90˚ (rectangle profile) [mm]  :  125 x 92
Depth of cutting at 90˚ (angle bar) [mm]  :  137 x  137
Depth of cutting at 90˚ (round profile) [mm]  :  100
Ext.dia.x.mountting dia.x.max.thickness [MM]  :  355 x 25,4 x 3

Input Power  :  450 W    GHO 500 PRO
No Load Speed  :  17000 rpm
Planing Width  :  82 mm
Planing Depth  :  2.5 mm
Rebating Dep  :  9 mm

Specifications
Mains voltage [V]  :   ̴ 230    GKS 235 PRO
Mains frequency [Hz]  :  50
Nominal power [W]  :  2000
Insulational class  :  II
Nominal rotation  [min‾ ¹]  :  4500
Ma ximum cutting depth (0˚/  45˚)  [mm]  :  83  /  62
Circular saw
     External diameter  [mm]  :  235
     Internal diameter  [mm]  :  25,4
     Maximum thicknes  [mm]  :  3,0

Motor                                                                                           Input  :  2 HP    AKS-MP400
Table                                                                                            Length  :  1340 mm
                                                                                                       Width  :  230  mm
Cutterhead                                                                                Speed 4400 r.p.m  /  50 Hz
                                                                                                       Number of knives  :  3
                                                                                                       Diameter  :  65 mm
                                                                                                       Size :  ₊̠  875 x 98 mm
Fence                                                                                           Tilit  :  45˚C in and out
                                                                                                       Width  :  200  mm
Cutting Capacity                                                                      Depth  :  3.175  mm
                                                                                                        Rabbeting  :  10 mm
